Innuos
Innuos ZENith Mk3
Innuos ZENith Mk3
Innuos ZENith Mk3
Triple-Linear Power Supply - ZENith Mk3
Inspired from the high-end power supply engineering of the SE, the ZENith Mk3 benefits from new premium Mundorf capacitors with ultra-low noise regulators and a medical-grade mains filter to provide even greater audio clarity.
Custom Motherboard - ZENith Mk3
Our own custom-made Innuos motherboard is completely reworked for optimised audio performance. Sources of EMI have been removed and internal clocks optimised, resulting in a "blacker" music background and enhanced realism.
Ultra-low Noise Streamer Output - ZENith Mk3
Dual-ethernet ports with isolation transformers provide an ultra-low noise network connection for your streamer, removing noise from the path and improving sound quality on all network audio.
Anti-vibration and EMI Treatment - ZENith Mk3
New asymmetrical isolation feet derived from our ZENith SE plus added treatment to the chassis help to combat harmful vibration that affect a clean audio signal, with even greater treatment now applied to the SSD.
In-Memory Playback - ZENith Mk3
With 4GB dedicated memory, the ZENith loads music directly to memory for playback so that it doesn’t need to engage the SSD during playback, improving sound quality.
AUDIO OUTPUTS |
|
| Digital Output | USB 2.0 supporting USB Audio Class 2, DoP, Native DSD and MQA |
| Dedicated Ethernet Streamer Port | |
CONNECTIVITY |
|
| Ethernet | 2 x rear panel RJ45 – Bridged Gigabit Ethernet |
| USB | 1x USB 2.0 (DAC), 1x USB 3.0 (Backup) |
FORMATS |
|
| CD Formats | Red Book |
| Disc Compatibility | CD, CD-R, CD-RW |
| Audio format for stored CDs | FLAC (zero compression), WAV |
| Audio Formats Supported for streaming and playing | WAV, AIFF, FLAC, ALAC, AAC, MP3, MQA (with supported DACs) |
SAMPLE RATES |
|
| Sample Rates | 44.1kHz, 48kHz, 88.2kHz, 96kHz, 176.4KHz. 192kHz, 352.8KHz, 384KHz , DSD64, DSD128, Native DSD up to DSD512 on selected DACs |
| Bit Depths | 16bit, 24bit, 32bit |
USER CONTROL INTERFACES |
|
| Web Interface | Web Browsers from iOS, Android (4.0 and up) or up-to-date Windows and OS X browsers |
| Mobile | App for iPhone/iPad, Android and Windows 10 |
HARDWARE |
|
| CD/DVD drive | TEAC Slot-loading drive |
| Hard Drive | 1TB SSD with Vibration and EMI treatment |
| CPU | Intel Quad Core N4200 |
| Memory | 8GB DDR3 Low-Voltage RAM (4GB Dedicated for RAM Playback) |
STREAMING AND CD STORAGE |
|
| UPnP/DLNA | Integrated UPnP Server |
| Streaming Services | Qobuz, Spotify Connect, Tidal, Internet Radio |
| Roon Compatibility | Roon Core and Roon Bridge |
| Average CD Storage Time | 5 minutes |
| CD Metadata | FreeDB, MusicBrainz, Discogs, GD3 |
| Compatible Music Systems | Sonos Multi-room Wireless Music System |
| DLNA/UPnP compatible devices | |
| USB DACs complying to USB Audio Class 2 | |
| USB DACs supporting DSD over DoP protocol | |
| Selected USB DACs supporting Native DSD | |
REQUIREMENTS |
|
| Network | Internet connection to access album metadata when storing CDs, Internet Radio, Streaming Services and software updates |
| Network router with at least one available ethernet port | |
| Premium subscription required for some streaming services such as Spotify, Qobuz and Tidal | |
| Recommended App (USB Connection Only) | iPeng 9 (iOS), OrangeSqueeze (Android), Squeeze Control (Windows 10) |
POWER |
|
| Mains Supply | 230V AC / 115V AC - Internal Triple-Linear Power Supply |
| Power Consumption | 12W when idle, 15W peak |
PHYSICAL |
|
| Dimensions | 70 x 420 x 320 mm (H x W x D) |
| Weight | 9 Kg |
| In the box | Innuos ZENith Mk3 1TB Music Server |
| Mains Cable | |
| 2m Ethernet Cable | |
| Getting Started leaflet |
