Quicksilver Line Stage Preamplifier
The latest version of the Quicksilver Line Stage offers a simplified switching and signal path. With almost 10 times the output current capability of the previous Line Stage it will drive any amplifier input impedance and interconnect cable with ease. The new Linestage embodies the Quicksilver philosophy “simplicity is the essence of good engineering”.
Optional home theater pass-through available, which routes the Video inputs directly to the preamp outputs when the preamp is off.
This preamp is shipped with J.J. 12AT7s, which Quicksilver feels provide the best sound, and have a life span of many thousands of hours. The J.J. 12AT7 is a new design and provides superior performance to new old stock 12AT7s.
The preamp is shipped with J.J. 12AT7s, which we feel provide the best sound, and have a life span of many thousands of hours. The J.J. 12AT7 is a new design and provides superior performance to new old stock 12AT7s.
| Bandwidth | 0.1 Hz to 100 KHz +0,-3db |
| IM Distortion | less than 0.08% at 1v output |
| Harmonic Distortion | less than 0.08% at 1v output from 10 Hz to 40 KHz |
| Gain | 18 db |
| Input Impedance | 100 Kohm, 20 Hz-20 KHz |
| Output Impedance | 100 ohms, 20 Hz-20 KHz |
| Output Polarity | inverted |
| Maximum Input | 30 volts RMS, 20 Hz-20 KHz |
| Maximum Output | 60 volts RMS, 20 Hz-20 KHz |
| Noise | 20 microvolts RMS residual IHF weighted noise output with gain control at minimum |
| Tube Complement | 2-12AT7 |
| Dimensions | 3″H, 9 1/2″D, 15″W |
| Front Panel | 3 1/4″H, 17″W |
| Weight | 12 lbs. |
| U.S. Warranty | 3 years parts and labor Tubes 90 days |
