ATC

ATC SCM7

ATC SCM7

Regular price Sale price $0.00
Sale Sold out
Contact us

ATC SCM7

New ATC designed and built 25mm soft dome HF unit with precision alloy wave guide.

125mm ATC mid/bass unit with integral soft dome.

In-house, hand-wound precision flat wire coil.
3Kg optimised motor assembly.
Massive optimised motor assembly.

Flat impedance curve allowing easy load for amplifiers.

6 year warranty.

Specifications

Drivers : HF 25mm Neodynium, Mid/LF 125mm
Matched Response : +/- 0.5dB
Frequency Response (-6dB) : 60Hz–22kHz
Dispersion : ±80° Coherent Horizontal, ±10° Coherent Vertical Sensitivity : 84dB @ 1W @ 1metre

Max SPL : 103dB
Recommended Power Amplifier : 75 to 300 Watts Nominal Impedance : 8 Ohm
Crossover Frequency : 2.5kHz
Connectors : Binding Posts/4mm Plugs, bi-wire Cabinet Dimensions (HxWxD) : 300x174x215mm Weight : 7.5kg
