Quicksilver Remote Control Line Stage Preamplifier
Improved soundstage width and depth and higher resolution are changes to the Quicksilver Remote Control Line Stage Preamplifier for 2012. In addition, a newly designed audio choke increases power and dynamics. The internal shielded cable has been eliminated, output impedance has been lowered and the power supply filtering and capacitance have been increased. A precision motorized Alps attenuator is still the best sounding volume control and video pass-through is available on request.
The preamplifier should be placed where it will have at least 4 inches of air circulation above it.
The hand held remote control adjusts the preamplifier volume up and down. This unit must be held facing the preamp front panel, within about 30 feet, to activate the pick-up on the preamp. The pick-up is located 3/4 inch to the left of the power switch. If the volume is all the way up or down, change the direction or release the button.
For more information please feel free to contact us. Please note this Quicksilver Remote Control Line Stage Preamplifier is phase inverting. All Quicksilver Audio products are proudly made in the USA.
"Like other Quicksilver products, the solidity of presentation, that is, dimensionality, imaging, and soundstaging, are quite remarkable." Paul Seydor, the absolute sound, October 2002.
Specifications
| Bandwidth | 0.1 Hz to 80 KHz |
| Gain | 18 db |
| Input Impedance | 50 Kohms, 20 Hz-20 KHz |
| Output Impedance | 600 ohms, 20 Hz-20 KHz |
| Output polarity | + 180 degrees |
| Tube Complement | 2-6DJ8, Note:6N1P or 6AQ8 tubes may be substituted |
| Chassis | carbide black |
| Dimensions | 3"H, 9 1/2"D, 15"W |
| Front Panel | 1/4" aluminum black anodized 17" x 3 1/4" |
| Weight | 12 lbs. |
| U.S. Warranty | 3 years parts and labor Remote control circuitry 1 year Tubes 90 days |
